Prestige 650 Series User’s Guide

System Information and Diagnosis

35-1

Chapter 35

System Information and Diagnosis

This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4.

35.1 System Maintenance Overview

These tools include updates on system status, port status, log and trace capabilities and upgrades for the
system software. This chapter describes how to use these tools in detail.

Type 24 in the main menu to open Menu 24

System Maintenance, as shown in the following figure.

Figure 35-1 Menu 24 System Maintenance

35.2 System Status

The first selection, System Status gives you information on the status and statistics of the ports, as shown
next. System Status is a tool that can be used to monitor your Prestige. Specifically, it gives you
information on your ADSL telephone line status, number of packets sent and received.

To get to System Status, type 24 to go to Menu 24 System Maintenance. From this menu, type 1.
System Status. There are two commands in Menu 24.1 System Maintenance Status. Entering 1
resets the counters; [ESC] takes you back to the previous screen.

Menu 24 - System Maintenance

1. System Status

2. System Information and Console Port Speed

3. Log and Trace
4. Diagnostic

5. Backup Configuration

6. Restore Configuration

7. Upload Firmware

8. Command Interpreter Mode

9. Call

Control

10. Time and Date Setting

11. Remote Management

Enter Menu Selection Number:
