Spartan-3A DSP FPGA Family: Pinout Descriptions
DS610 (v3.0) October 4, 2010 www.xilinx.com
Product Specification 83
GND GND F21 GND
GND GND F26 GND
GND GND C3 GND
GND GND C9 GND
GND GND C14 GND
GND GND C19 GND
GND GND C24 GND
GND GND AF1 GND
GND GND AF6 GND
GND GND AF11 GND
GND GND AF16 GND
GND GND AF21 GND
GND GND AF26 GND
GND GND AD3 GND
GND GND AD8 GND
GND GND AD13 GND
GND GND AD18 GND
GND GND AD24 GND
GND GND AA1 GND
GND GND AA6 GND
GND GND AA11 GND
GND GND AA16 GND
GND GND AA21 GND
GND GND AA26 GND
GND GND A1 GND
GND GND A6 GND
GND GND A11 GND
GND GND A16 GND
GND GND A21 GND
GND GND A26 GND
VCCAUX SUSPEND V20 PWRMGMT
VCCAUX DONE AB21 CONFIG
VCCAUX PROG_B A2 CONFIG
VCCAUX TDI G7 JTAG
VCCAUX TDO E23 JTAG
VCCAUX TMS D4 JTAG
VCCAUX TCK A25 JTAG
VCCAUX VCCAUX V9 VCCAUX
VCCAUX VCCAUX U14 VCCAUX
Table 66: Spartan-3A DSP FG676 Pinout for
XC3SD1800A FPGA (Cont’d)
Bank XC3SD1800A Pin Name
FG676
Ball
Type
VCCAUX VCCAUX T22 VCCAUX
VCCAUX VCCAUX P17 VCCAUX
VCCAUX VCCAUX N10 VCCAUX
VCCAUX VCCAUX L5 VCCAUX
VCCAUX VCCAUX K13 VCCAUX
VCCAUX VCCAUX J18 VCCAUX
VCCAUX VCCAUX E5 VCCAUX
VCCAUX VCCAUX E16 VCCAUX
VCCAUX VCCAUX E22 VCCAUX
VCCAUX VCCAUX AB5 VCCAUX
VCCAUX VCCAUX AB11 VCCAUX
VCCAUX VCCAUX AB22 VCCAUX
VCCINT VCCINT U12 VCCINT
VCCINT VCCINT T11 VCCINT
VCCINT VCCINT T13 VCCINT
VCCINT VCCINT T15 VCCINT
VCCINT VCCINT R12 VCCINT
VCCINT VCCINT R14 VCCINT
VCCINT VCCINT R16 VCCINT
VCCINT VCCINT P11 VCCINT
VCCINT VCCINT P13 VCCINT
VCCINT VCCINT P14 VCCINT
VCCINT VCCINT P15 VCCINT
VCCINT VCCINT N12 VCCINT
VCCINT VCCINT N13 VCCINT
VCCINT VCCINT N14 VCCINT
VCCINT VCCINT N16 VCCINT
VCCINT VCCINT M11 VCCINT
VCCINT VCCINT M13 VCCINT
VCCINT VCCINT M15 VCCINT
VCCINT VCCINT M17 VCCINT
VCCINT VCCINT L12 VCCINT
VCCINT VCCINT L14 VCCINT
VCCINT VCCINT L16 VCCINT
VCCINT VCCINT K15 VCCINT
Table 66: Spartan-3A DSP FG676 Pinout for
XC3SD1800A FPGA (Cont’d)
Bank XC3SD1800A Pin Name
FG676
Ball
Type
