Spartan-3A DSP FPGA Family: DC and Switching Characteristics
DS610 (v3.0) October 4, 2010
Product Specification
40
Clock Buffer/Multiplexer Switching Characteristics
Table 32: Clock Distribution Switching Characteristics
Symbol
Description
Minimum
Maximum
Units
Speed Grade
-5
-4
T
GIO
Global clock buffer (BUFG, BUFGMUX, BUFGCE) I input to
O-output delay
–
0.22
0.23
ns
T
GSI
Global clock multiplexer (BUFGMUX) select S-input setup to I0 and
I1 inputs. Same as BUFGCE enable CE-input
–
0.56
0.63
ns
F
BUFG
Frequency of signals distributed on global buffers (all sides)
0
350
334
MHz
Notes:
1.
The numbers in this table are based on the operating conditions set forth in
