Spartan-3A DSP FPGA Family: DC and Switching Characteristics
DS610 (v3.0) October 4, 2010
Product Specification
30
LVCMOS25
Slow
2 mA
5.33
5.33
ns
4 mA
2.81
2.81
ns
6 mA
2.82
2.82
ns
8 mA
1.14
1.14
ns
12 mA
1.10
1.10
ns
16 mA
0.83
0.83
ns
24 mA
2.26
2.26
ns
Fast
2 mA
4.36
4.36
ns
4 mA
1.76
1.76
ns
6 mA
1.25
1.25
ns
8 mA
0.38
0.38
ns
12 mA
0.00
0.00
ns
16 mA
0.01
0.01
ns
24 mA
0.01
0.01
ns
QuietIO
2 mA
25.92
25.92
ns
4 mA
25.92
25.92
ns
6 mA
25.92
25.92
ns
8 mA
15.57
15.57
ns
12 mA
15.59
15.59
ns
16 mA
14.27
14.27
ns
24 mA
11.37
11.37
ns
Table 25:
Output Timing Adjustments for IOB
(Cont’d)
Convert Output Time from
LVCMOS25 with 12mA Drive
and Fast Slew Rate to the
Following Signal Standard
(IOSTANDARD)
Add the
Adjustment
Below
Units
Speed Grade
-5
-4
LVCMOS18
Slow
2 mA
4.48
4.48
ns
4 mA
3.69
3.69
ns
6 mA
2.91
2.91
ns
8 mA
1.99
1.99
ns
12 mA
1.57
1.57
ns
16 mA
1.19
1.19
ns
Fast
2 mA
3.96
3.96
ns
4 mA
2.57
2.57
ns
6 mA
1.90
1.90
ns
8 mA
1.06
1.06
ns
12 mA
0.83
0.83
ns
16 mA
0.63
0.63
ns
QuietIO
2 mA
24.97
24.97
ns
4 mA
24.97
24.97
ns
6 mA
24.08
24.08
ns
8 mA
16.43
16.43
ns
12 mA
14.52
14.52
ns
16 mA
13.41
13.41
ns
LVCMOS15
Slow
2 mA
5.82
5.82
ns
4 mA
3.97
3.97
ns
6 mA
3.21
3.21
ns
8 mA
2.53
2.53
ns
12 mA
2.06
2.06
ns
Fast
2 mA
5.23
5.23
ns
4 mA
3.05
3.05
ns
6 mA
1.95
1.95
ns
8 mA
1.60
1.60
ns
12 mA
1.30
1.30
ns
QuietIO
2 mA
34.11
34.11
ns
4 mA
25.66
25.66
ns
6 mA
24.64
24.64
ns
8 mA
22.06
22.06
ns
12 mA
20.64
20.64
ns
Table 25:
Output Timing Adjustments for IOB
(Cont’d)
Convert Output Time from
LVCMOS25 with 12mA Drive
and Fast Slew Rate to the
Following Signal Standard
(IOSTANDARD)
Add the
Adjustment
Below
Units
Speed Grade
-5
-4
