Job Editor 67
The Imposed Sheets Tab
The Imposed Sheets tab is available only for imposed RTP jobs. This tab
enables you to view the imposed sheets and check your imposition
parameters. You cannot edit the job on this tab.
To display a page of an Imposed job:
1. Click the Thumbnails or Booklets tab.
2. Select the desired thumbnail or page.
3. Click the Imposed sheets tab.
The selected page of the imposed job appears.
Note: The Imposed Sheets tab is available only if you have the Pro configuration.
Notes:
• In VI jobs, the booklet number appears in instead of the sheet number — for
example, Booklet 1, Page 15.
• In duplex jobs, each sheet is displayed twice, once for side A, and once for
side B. For example, Sheet 1, Side A.
