194 Appendix A– Setting Parameters
4. In the Rows list, select the number of pages to place vertically.
5. Select the desired layout—for example, Duplex HTH or Duplex HTT .
6. Select the North South check box if the template you chose is either
step and repeat 2×1 or 1×2. The pages will be placed 180 degrees from
each other, on the same side of the imposed sheet.
User-Defined Imposition Templates
The Imposition Template area enables you to import and manage user-
defined imposition templates that were created in a stand-alone
application—for example, Ultimate inSpire.
To import a user-defined imposition template:
1. On the toolbar, click the Resource Center button .
2. In the Resource list, select Imposition Templates .
3. Click the Import button .
Note: User-defined imposition templates are available only if you have the Pro
configuration.
Note: This option is available only if you have the Pro configuration.
