F3200 Installation & Programming Manual Document No: LT0122
System Specifications
Page 3-20 5 July 2001 Issue 2.7
3.7 DISPLAYS
Standard Display
Includes : LCD; FFCIF LEDs; System Status LEDs
Panel Size : 19", 4U
FFCIF Type : 3 (common indicators & common controls)
Standard : Complies with AS4050 (int) - 1992
LCD Size : 2 Lines of 40 characters
5.5mm (H) x 3.2mm (W) per character
Site Name : 40 Characters max.
Zone Name : 30 Characters max.
Relay Name : 30 Characters max.
FFCIF LEDs : ALARM (red); ISOLATED (yellow); FAULT (yellow)
System
Status LEDs : MAINS ON (green); CHGR/BATT FAULT (yellow); SYSTEM FAULT
(yellow); ANCILLARY ISOLATED (yellow); BELLS ISOLATED (yellow)
Internal : Mains On (green), Fuse Blown (yellow) on MAF/PSU pcb.
Status
LEDs
Optional Additional Display
Requires 1 x ME0060 plus: 1 x FZ3031 plus 1-3 FP0475 as required.
Note: FZ3031 contains the FRC cable (LM0092) that is
required to connect the Controller Board to the first
Display Board.
ME0060, MECH ASSY, 1901-79, F4000 RAC, EXT INNER DOOR
(19", 7U, mounts up to 4 of 16 Zone LED Display Bd)
FP0475, FP, 16 ZONE LED DISPLAY EXTENDER KIT, 1901-26
Includes : 1 x 16 Zone LED Display Bd; FRC; Power leads; zone name label
(FP0475 has 0.5m FRC, FZ3031 has 1.2m FRC).
Format : 7U Parallel LED display mounts directly below the standard 4U LCD.
The LCD and common LEDs operate as per standard. Zone status is
additionally shown on the zone LEDs.
FFCIF Type : 2 (individual zone indicators and common controls)
Zone LEDs : ALARM (red); FAULT (yellow); ISOLATED (yellow)
Name Space : 10mm x 60mm per zone on paper label.
E.g. 2 lines of 23 characters at 10 per inch.
