F3200 Installation & Programming Manual Document No: LT0122
Network Programming
Page 11-24 5 July 2001 Issue 2.7
11.12 DEFAULT VALUES FOR PANEL-LINK VARIABLES
Item Parameters Default
Network Setup
Local SID Number 1-254 0
Mode Multidrop/Pnt to Pnt Multidrop
NIC Yes/No No
RX Timeout 1-250 5 millisecs 2
TX Delay 1-250 5 millisecs 1
ACK Time 1-9999 millisecs 800
DUP Time 1-9000 millisecs 2000
Leading FF 0-250 characters 1
Trailing FF 0-250 seconds 1
Link TX Yes/No Yes
Link Tx Time 1-250 seconds 5
Link RX Time 1-250 seconds 50
Groups Any combination of 1 [12345678]
to 8
ACK Broadcasts Yes/No No
Baud rate 300 up to 19200 9600
Retries 0-15 5
Slots 8, 16, 32 8
Mode B 0-7 3
ACK Bcasts Specific SID 0-254 0
Network SID Configuration (per SID)
Link RX Yes/No No
Log Events Yes/No No
RX FFCIF Yes/No No
TX CMD Yes/No No
RX CMD Yes/No No
Use MAF data Yes/No No
Use MAF totals Yes/No No
Status search Yes/No No
Network MAF Config
Refresh TX Time 1-250 seconds 20
Max COS rate 0-250 seconds 2
Receive net bells
control Yes/No No
Send net silence Yes/No No
Receive net silence Yes/No No
Network Command Config
ACK Time 1-250 seconds 10
Work Time 1-250 seconds 3
RX net time/date Yes/No Yes
TX net time/date Yes/No No
FFCIF Config
TX Alarms Yes/No No
Dedicated TX SID 0-254 (0=all) 0
RX Net ACK Yes/No No
TX iso/reset cmds Yes/No No
TX ack cmds Yes/No No
