Page 69

46
Module Current Consumption
Section 2-6
Motion Control Modules
Current Consumption for 24-V Systems
Example Calculation
of Current and Power
Consumption
Example for CJ1W-PA202 Power Supply Unit with the Following Modules
Mounted
Combining Power
Supply Units and
Motion Control
Modules
The following table shows the Power Supply Units that can be connected for
different numbers of Motion Control Modules.
Note
These combinations are not possible because the current consumption
exceeds the capacity of the Power Supply Unit.
Name
Type
Model
5-V system current
consumption (A)
Motion Control Module
Pulse I/O
FQM1-MMP21
0.836
Analog I/O
FQM1-MMA21
0.843
Name
Type
Model
24-V system current
consumption (A)
Motion Control Module Analog I/O
FQM1-MMA21
0.104
Name
Model
Quantity
Voltage system
5 V
24 V
Coordinator
Module
FQM1-CM001
1
0.47 A
---
Motion Control
Module
FQM1-MMP21
1
0.836 A
---
FQM1-MMA21
1
0.843 A
0.104 A
Current con-
sumption
Calculation
0.47 + 0.836 +
0.843
0.104 A
Result
2.15 A (
≤ 2.8 A) 0.104 × 24 V =
2.5 W
Power con-
sumption
Calculation
2.15
× 5 V =
10.75 W
---
Result
10.75 + 2.5 = 13.75 W (
≤ 14 W)
Number of axes
Number of connected Motion Control
Modules
Power Supply Unit
FQM1-MMP21
FQM1-MMA21
2
1
0
CJ1W-PA202 (or
CJ1W-PA205R)
0
1
4
2
0
1
1
0
2
CJ1W-PA205R
6
3
0
2
1
1
2
0
3
8
4
0
3
1
2
2
1
3
Not possible
(See note.)
0
4
