Page 395: Block programming instructions

372
Auxiliary Area Allocations
Appendix D
Serial Communications Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Debugging Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Failure Diagnosis Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Other Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Block Programming Instructions
Instruction
Mnemonic
Code
Length
(steps)
(See
note.)
ON execution
time (
µs)
Hardware
implementation
Conditions
TRANSMIT
TXD
236
4
24.1
---
Sending 1 byte
342.6
---
Sending 256 bytes
RECEIVE
RXD
235
4
36.2
---
Storing 1 byte
348.9
---
Storing 256 bytes
CHANGE SERIAL
PORT SETUP
STUP
237
3
441.1
---
---
Instruction
Mnemonic
Code
Length
(steps)
(See
note.)
ON execution
time (
µs)
Hardware
implementation
Conditions
TRACE MEMORY
SAMPLING
TRSM
045
1
34.6
---
Sampling 1 bit and 0 words
148.3
---
Sampling 31 bits and 6 words
Instruction
Mnemonic
Code
Length
(steps)
(See
note.)
ON execution
time (
µs)
Hardware
implementation
Conditions
FAILURE ALARM
FAL
006
3
157.1
---
Recording errors
56.0
---
Deleting errors (in order of priority)
457.0
---
Deleting errors (all errors)
53.6
---
Deleting errors (individually)
SEVERE FAILURE
ALARM
FALS
007
3
---
---
---
Instruction
Mnemonic
Code
Length
(steps)
(See
note.)
ON execution
time (
µs)
Hardware
implementation
Conditions
SET CARRY
STC
040
1
0.15
Yes
---
CLEAR CARRY
CLC
041
1
0.15
Yes
---
Instruction
Mnemonic
Code
Length
(steps)
(See
note.)
ON execution
time (
µs)
Conditions
BLOCK PROGRAM
BEGIN
BPRG
096
2
20.3
---
---
BLOCK PROGRAM
END
BEND
801
1
17.2
---
---
