331
System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations
Appendix C
A609
00
High-speed
counter 2 status
Target Compar-
ison In-
progress Flag
Same as for high-speed counter 1.
Module
01
PV Overflow/
Underflow Flag
02
Reserved
03
Phase Z Input
Reset Flag (ON
for one cycle)
04
Absolute No. of
Rotations Read
Error Flag
05
Absolute No. of
Rotations Read
Completed
Flag
06
Measuring Flag
(measurement
mode 1 or 2)
07
High-speed
Counter Oper-
ating Flag
08
Count Latched
Flag
09 to 11
Reserved
12
Absolute Off-
set Preset
Error Flag
13 to 15
Reserved
Address
Bits
Name
Function
Controlled
by
