369
Auxiliary Area Allocations Appendix D
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Table Data Processing Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Data Control Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Subroutine Instructions
Note When a double-length operand is used, add 1 to the value shown in the length column in the above
table.
Floating Symbol Com-
parison LD, AND, OR +=F 329 3 8.9 --- ---
LD, AND, OR +<>F 330
LD, AND, OR + 331
LD, AND, OR +<=F 332
LD, AND, OR +>F 333
LD, AND, OR +>=F 334
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time ( µs)
Hardware
implementation
Conditions
FIND MAXIMUM MAX 182 4 13.0 --- Searching for 1 word
1.41 ms --- Searching for 1,000 words
FIND MINIMUM MIN 183 4 12.8 --- Searching for 1 word
1.412 ms --- Searching for 1,000 words
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time ( µs)
Hardware
implementation
Conditions
SCALING SCL 194 4 22.7 --- ---
SCALING 2 SCL2 486 4 21.8 --- ---
SCALING 3 SCL3 487 4 26.1 --- ---
AVERAGE AVG 195 4 27.9 --- Average of an operation
27.9 --- Average of 64 operations
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time ( µs)
Hardware
implementation
Conditions
SUBROUTINE CALL SBS 091 2 25.5 Yes ---
SUBROUTINE ENTRY SBN 092 2 --- --- ---
SUBROUTINE
RETURN RET 093 1 21.9 Yes ---
MACRO MCRO 099 4 47.4 --- ---
JUMP TO SUBROU-
TINE JSB 982 4 34.9 --- ---
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution
time ( µs)
Hardware
implementation
Conditions
