System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations Appendix C
FQM1-MMP21 Motion Control Modules with Pulse I/O
CX-Programmer: Pulse Input Tab Page
Address Bits Function Remarks When setting is
read
+320 00 to 03 High-speed
counter 1 (Counter
1)
Input method 0 hex: Phase differential x1
1 hex: Phase differential x2
2 hex: Phase differential x4
3 hex: Increment/decrement pulse inputs
4 hex: Pulse + direction inputs At power ON
04 to 07 Reset method 0 hex: Software reset
1 hex: Phase Z and software reset
08 to 11 Counting speed 0 hex: 50 kHz
1 hex: 500 kHz
12 to 15 Counter operating
mode (Counter opera-
tion) 0 hex: Linear counter
1 hex: Circular counter
2 hex: Absolute linear counter (CW
−)
3 hex: Absolute circular counter
4 hex: Absolute linear counter (CW+)
Note When setting any mode except for a linear
counter (0 hex), be sure to set the Circular Maxi-
mum Count/Absolute Encoder Resolution.
+321 00 to 03 Counter data to moni-
tor (Counter data dis-
play) 0 hex: Do not monitor (Non-monitor)
1 hex: Counter PV changes (Counter movements
(mode 1))
2 hex: Frequency (mode 2)
Note The frequency (mode 2) can be set only for
high-speed counter 1.
04 to 15 Reserved
+322 00 to 15 Sampling time (for
mode 1 only) Sets the sampling time for monitoring counter PV
changes (mode 1)
0000: Cycle time
0001 to 270F hex: 1 to 9,999 ms
(unit: 1 ms)
Note This setting is valid only when the Counter
Data Display (bits 00 to 03 of +321) is set to 1 hex
(mode 1).
