System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations Appendix C
A562 00 Analog Output 1
Flags User Adjustment Com-
pleted Initial value is 0.
Set to 1 if user performs offset/gain adjustment and
Returns to factory default setting of 0 if adjustment
value is cleared. Module
01 to 03 Reserved ---
04 Operating ON: ON while the analog output is being changed by
ACC(888).
OFF: Turned OFF when target value is reached.
05 to 07 Reserved ---
08 Output SV Error ON: ON when the output SV setting is outside of the
allowed setting range.
OFF: OFF when the output SV is within range.
Note Only for END refresh.
09 to 11 Reserved ---
12 Factory Adjustment Value
Error ON: ON when the factory-set data stored in flash
memory is invalid.
OFF: OFF when the factory-set data stored in flash
memory is normal.
13 Reserved ---
14 User Adjustment Value
Error ON: ON when the user-set adjustment value stored
in flash memory is invalid.
OFF: OFF when the user-set adjustment value
stored in flash memory is normal.
15 Reserved ---
A563 00 Analog Output 2
Flags User Adjustment Com-
pleted Same as for Analog Output 1 Flags.
01 to 03 Reserved
04 Operating
05 to 07 Reserved
08 Output SV Error
09 to 11 Reserved
12 Factory Adjustment Value
Error
13 Reserved
14 User Adjustment Value
Error
15 Reserved
