Page 261

238
Connecting the CX-Programmer
Section 8-2
8-2-2
CX-Programmer Connecting Cables
Note
When connecting one of these cables to the Coordinator Module’s RS-232C
port, always touch a grounded metal object to discharge any electrostatic
charge from the body before touching the cable connector.
The XW2Z-
@@@S-CV Cables are equipped with static-resistant XM2S-0911-
E Connector Hoods to improve static resistance, but we recommend discharg-
ing static build-up before touching these connectors as well.
!Caution The OMRON Cables listed above can be used for connecting cables or an
appropriate cable can be assembled. The external device or Coordinator
Module itself may be damaged if a standard computer RS-232C cable is used
as a connecting cable.
USB
Connecting
Cable
Cable 1
Cable 2
Port
Communic
ations
mode
Connector
Model
Connector
Connector
Model
Connector
CS1F-CIF31 D-Sub 9-pin
female
CS1W-
CN226/626
(2 or 6 m)
CS/CJ
peripheral
Unnecessary
Coordinator
Module
peripheral
Peripheral
bus (Tool
bus) or
Host Link
D-Sub 9-pin
female
XW2Z-
200S-CV/
500S-CV
(2 or 5 m)
D-Sub 9-pin
male
D-Sub 9-pin
female
CS1W-
CN118
(0.1 m)
CS/CJ
peripheral
Peripheral
bus (Tool
bus) or
Host Link
D-Sub 9-pin
female
XW2Z-
200S-V/
500S-V
(2 or 5 m)
D-Sub 9-pin
male
D-Sub 9-pin
female
CS1W-
CN118
(0.1 m)
CS/CJ
peripheral
Host link
D-Sub 9-pin
female
XW2Z-
200S-CV/
500S-CV
(2 or 5 m)
RS-232C
D-Sub 9-pin
male
Unnecessary
RS-232C
D-Sub 9-pin
female
Peripheral
bus (Tool
bus) or
Host Link
D-Sub 9-pin
female
XW2Z-
200S-V/
500S-V
(2 or 5 m)
RS-232C
D-Sub 9-pin
male
Unnecessary
Host link
Port on Module Computer
Port on
computer
Communications mode
(Network type)
Model
Length
Remarks
Built-in periph-
eral port
Windows
OS
D-Sub 9-pin
male
Peripheral bus (Tool bus)
or Host Link (SYSMAC
WAY)
CS1W-CN226
2.0 m
---
CS1W-CN626
6.0 m
Built-in RS-232C
port
(D-Sub 9-pin
female)
Windows
OS
D-Sub 9-pin
male
Peripheral bus (Tool bus)
or Host Link (SYSMAC
WAY)
XW2Z-200S-CV
2 m
Uses static-
resistant con-
nectors
XW2Z-500S-CV
5 m
