339
System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations Appendix C
Address Bits Name Function Controlled by
A600 00 to 15 High-speed Counter 1 PV Range: 8000 0000 to 7FFF FFFF
Note For a Linear Counter, high-speed counter over-
flows/underflows are checked when the PV is read
(i.e., when Module internal I/O is refreshed).
Module
A601 00 to 15
A602 00 to 15 High-speed Counter 2 PV
A603 00 to 15
A604 to
A605 00 to 15 High-
speed
Counter
1 For following
counter modes
• Absolute linear
(CW −)
• Absolute circu-
lar
• Absolute linear
(CW+)
PV of abso-
lute number
of rotations Contains the number of rotations data (PV) read from
the Encoder when the SEN signal is input to the
Servo Driver.
8000 0000 to 7FFF FFFF hex
For following
counter modes
• Linear counter
• Circular
counter
Monitor data • When monitoring counter movements (mode 1),
contains the absolute value of the amount of
change in the PV of the high-speed counter over
the specified sampling time as a 8-digit hexadeci-
mal value (0000 0000 to FFFF FFFF hex).
• When monitoring the counter frequency (mode 2),
contains the frequency of the high-speed counter
calculated from the PV of the high-speed counter
between 0 and 7A120 hex (0 and 500 kHz).
A606 to
A607 00 to 15 High-
speed
Counter
2 For following
counter modes
• Absolute linear
(CW −)
• Absolute circu-
lar
• Absolute linear
(CW+)
PV of abso-
lute number
of rotations Same as for A604 and A605 for high-speed counter
1 except that measuring the high-speed counter fre-
quency is not possible for high-speed counter 2.
For following
counter modes
• Linear counter
• Circular
counter
Monitor data
