System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations
Appendix C
Coordinator Module Built-in I/O Allocations
Inputs (40-pin General-purpose I/O Connector)
Outputs (40-pin General-purpose I/O Connector)
Motion Control Module Built-in I/O Allocations
Inputs (26-pin General-purpose I/O Connector)
Outputs (26-pin General-purpose I/O Connector)
Name
I/O Area allocations
External input 0
CIO 0000.00
External input 1
CIO 0000.01
to
to
External input 15
CIO 0000.15
Name
I/O Area allocations
External output 0
CIO 0001.00
External output 1
CIO 0001.01
to
to
External output 7
CIO 0010.07
Name
I/O Area allocations
External input 0 (interrupt) CIO 0000.00
External input 1 (interrupt) CIO 0000.01
External input 2 (interrupt) CIO 0000.02
External input 3 (interrupt) CIO 0000.03
to
to
External input 11
CIO 0000.11
Name
I/O Area allocations
External output 0
CIO 0001.00
External output 1
CIO 0001.01
to
to
External output 7
CIO 0001.07
