Use the Océ TDS600 to print

Printer operator panel actions

On the Océ TDS600 printer operator panel you can perform a limited number
of actions:

■

Set the media type

■

Set the media type for manual feeder

■

Set the media size

■

Set a special media indication

■

Stop a print job

■

Select the preferred language

■

Make off-line folding settings

■

Clean the reinforcement knives

Media type and size on the printer

One of the features of the Océ TDS600 printer is the automatic media change
function. This function allows the printer to switch to another roll of the same
format and copy material when the roll or sheet feeder becomes empty during
printing.

Note:

Since the Océ TDS600 Printer cannot detect the loaded copy material

type and format itself, you have to specify type and size after you (re)load
media, as described in ‘Media’ on page 240.

See ‘List of available material types and sizes’ on page 309 for an overview of
all materials that can be used on the Océ TDS600 Printer.

▼

Set media type

Press the on line button on the printer operating panel to put the printer off line.
The message ‘Off line’ is displayed in the status window.
