280 Océ TDS600 Multifunctional Digital System User Manual
▼ ▼ ▼ ▼ Clear a jam in the belt unit
1 Open the door of the belt unit (see figure 179).
[179] Opening the belt unit door
2 Squeeze the two green knobs in the upper section of the belt unit and open the
plate (see figure 180).
[180] Opening the plate
3 Remove any jammed printing material.
4 Squeeze the two knobs again and put the plate in its original position.
