Supplemental Information
Roland VS-2480 Owner’s Manual www.rolandus.com 407
Control Change Numbers—Track Channel Parameters
TRACK STATUS Buttons—The Effects of Control Change Values
You can change the current setting of a TRACK STATUS button by sending Control
Change messages to the VS-2480. Tracks 1-16 respond to Control Change 35. Tracks
17-24 respond to Control Change 67. The following table shows how a TRACK STATUS
button’s setting changes in response to various received Control Change values
.
Track Channels 1-16 Track Channels 17-24
Control Change Parameter Control Change Parameter
35 TRACK STATUS 67 TRACK STATUS
39 Fader Level 71 Fader Level
42 Pan 74 Pan
44 Aux 1 Send Level 76 Aux 1 Send Level
45 Aux 2 Send Level 77 Aux 2 Send Level
46 Aux 3 Send Level 78 Aux 3 Send Level
47 Aux 4 Send Level 79 Aux 4 Send Level
48 Aux 5 Send Level 80 Aux 5 Send Level
49 Aux 6 Send Level 81 Aux 6 Send Level
50 Aux 7 Send Level 82 Aux 7 Send Level
51 Aux 8 Send Level 83 Aux 8 Send Level
52 Aux 1/2 Send Pan 84 Aux 1/2 Send Pan
53 Aux 3/4 Send Pan 85 Aux 3/4 Send Pan
54 Aux 5/6 Send Pan 86 Aux 5/6 Send Pan
55 Aux 7/8 Send Pan 87 Aux 7/8 Send Pan
56 Offset Fader Level 88 Offset Fader Level
57 Offset Pan 89 Offset Pan
Values from 0-41 Values from 42-83 Values from 84-127
With the Off → same Off → Record-ready Off → Play
VS-2480 Play → Off Play → Record-ready Play → same
stopped Record-ready → Off Record-ready → same Record-ready → Play
X=ignored Values from 0-41 Values from 42-83 Values from 84-127
During Off → X Off → X Off → Play
playback & Play → Off Play → X Play → X
recording Record → X Record → X Record → X
