Factory EZ Routing Templates
The VS-2480 ships with seven EZ Routing templates—see Page 296 for information on
EZ Routing templates. The settings contained in the factory templates are as follows.
Recording Template
Patch Bay: Input Mixer: Recording Track:
ANALOG INPUT 1 1 1
: :
ANALOG INPUT 16 16 16
OUTPUT ASSIGN:
Track Direct Out Off
LINK:
Ch Link Off (IN1–16, TR1–16)
TRACK STATUS:
TR1 REC
: :
TR16 REC
TR17 Off
: :
TR24 Off
. . .
. . .
. . .
ANALOG
INPUT 1-16
INPUT
MIXER 1-16
TRACK
MIXER 1-16
MASTER L/R
Input
Patch Bay
TRACK
ASSIGN
RECORDING
TRACK
V.Track
1-1
MIX
. . . 1 2 3 14 15 16
