97
Other Functions
Other Functions
Transmitting Data to an
External MIDI Device (Data
Transfer)
Patch, setup and system settings will be transmitted to an external
MIDI device. This operation is called
bulk dump . Use this operation
when you want to connect another V-Synth and play it using the
same settings, or to save your data on an external MIDI device as a
precaution against possible loss of sound data or system settings.
To transmit data to an external MIDI device, connect the external
MIDI device and V-Synth as shown in the diagram.
fig.08-01.e
1. Touch < ▼ > in the upper right of the screen.
A pulldown menu appears.
fig.01-05_50
2. In the pulldown menu, touch .
The Data Transfer window appears.
fig.08-02_50
3. In “Source,” select the type of data that you want to
transmit.
: Patch, setup, system
: Setup
: System
: Patch
If you selected , specify the patch that is to be sent.
: Transmit patches from the work area. Use the
“FROM” - “TO” fields to specify the range of patch numbers
(001–512) that will be transmit.
: Transmit patch from the temporary area.
4. Set the external MIDI device so that it will be ready to receive
data, and touch to execute data transmission.
While the data is being transmitted, the display will indicate
“Transmitting...” When “COMPLETED!” is displayed, the
transmission has been completed.
To halt during transmission, touch .
MIDI OUT
V-Synth
MIDI IN
MIDI Sequencer
