157
MIDI Implementation
Appendices
2. Data Transmission
■ Channel Voice Messages
● Note Off
Status 2nd byte 3rd byte
8nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
● Note On
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
● Control Change
* By selecting a controller number that corresponds to the setting of parameters of
controllers (Time Trip Pad, D Beam, Knob, and so on), the V-Synth can transmit any
control change message.
❍ Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* These messages are transmitted when Patch is selected. But not transmitted when
Transmit Program Change or Transmit Bank Select parameter (SYSTEM Com MIDI/
USB) is OFF.
* Although with the V-Synth you can select the Bank Select messages to be transmitted, be
sure to refer to the Program Change Map on (p. 153) for the Bank Select messages
transmitted when the V-Synth is select a Patch, Rhythm Set, Multitimbre or
Performance.
❍ Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
❍ Breath Type MSB (Controller number 2)
Status 2nd byte 3rd byte
BnH 02H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
❍ Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
❍ General Purpose Controller 1 MSB (Controller number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 2 MSB (Controller number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 3 MSB (Controller number 18)
Status 2nd byte 3rd byte
BnH 12H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 4 MSB (Controller number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Breath Type LSB (Controller number 34)
Status 2nd byte 3rd byte
BnH 22H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 1 LSB (Controller number 48)
Status 2nd byte 3rd byte
BnH 30H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 2 LSB (Controller number 49)
Status 2nd byte 3rd byte
BnH 31H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 3 LSB (Controller number 50)
Status 2nd byte 3rd byte
BnH 32H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 4 LSB (Controller number 51)
Status 2nd byte 3rd byte
BnH 33H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
❍ General Purpose Controller 5 (Controller number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 6 (Controller number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 7 (Controller number 82)
Status 2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 8 (Controller number 83)
Status 2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
