Roland V-Synth - Manual (Page 121)

121
Effects List
Appendices
09: Dynamic Processor
(Stereo Dynamic Processor)
A comp/limiter, enhancer, 3-band equalizer, and noise suppressor
are connected in series.
Comp/Limiter is able to use as a compressor, which controls
inconsistencies in sound levels by suppressing high sound levels
while lifting weaker signals, or as a limiter that prevents the signal
from reaching exceedingly high levels.
Enhancer regulates the high-end overtones, clarifying the sound and
the sound contour.
3-Band Equalizer works in three frequency ranges: Low, Mid, and
High. You can set the frequencies and boost or cut the level.
Noise Suppressor leaves the original sound unmodified, but mutes
only the noise during the silent intervals.
fig.MFX-09
10: Tape Echo Simulator
This virtual tape echo gives you real tape delay sound. This
simulates the tape echo part of Roland’s RE-201 Space Echo.
fig.MFX-10
Parameter Value Description
Comp Sw OFF, ON Turns the comp/limiter on/off.
Comp Thresh-
old #1 -60–0 dB Sets the volume level at which
the compression begins.
Comp Attack 0–127 Sets the time after the sound vol-
ume is crossed the compressor
threshold until compression be-
gins.
Comp Release 0–127 Specifies the time from when the
volume drops below the com-
pressor threshold until com-
pression is no longer applied.
Comp Ratio 1.5:1, 2:1, 4:1,
100:1 Sets the “source sound:output
sound” compression ratio.
Comp Gain -60– +12 dB Output gain
Enhan Sw OFF, ON Turns the enhancer on/off.
Enhan Sens 0–127 Sensitivity of the enhancer
Enhan Frequen-
cy 0–127 Sets the lower limit of the fre-
quencies to which the enhance-
ment effect is added.
Enhan Mix Lev-
el 0–127 Level of the overtones generated
by the enhancer
Enhan Level 0–127 Volume of the enhancer sound
EQ Low Freq 50–4000 Hz Frequency of the low range
EQ Low Gain -15– +15 dB Gain of the low range
EQ Mid Freq 50–20000 Hz Frequency of the middle range
EQ Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0 Gain of the middle range
Set a higher value for Q to nar-
row the range to be affected.
EQ Mid Gain -15– +15 dB Gain of the middle range
EQ Hi Freq 2000–20000 Hz Frequency of the high range
EQ Hi Gain -15– +15 dB Gain of the high range
NS Sw OFF, ON Turns the noise suppressor on/
off.
NS Threshold
#2 0–127 Adjusts the level at which the
noise suppressor will begin to
take effect.
* When the signal drops below
the specified level, it will be
muted.
L
R
Comp/
Limiter 3-Band
EQ
Noise
Suppressor
Enhancer
NS Release 0–127 Sets the transition time from
when the noise suppression
starts to the point where the vol-
ume reaches 0.
Parameter Value Description
Mode S, M, L, S+M,
S+L, M+L,
S+M+L Sets the combination of play-
back heads to be used.
The RE-201 had three playback
heads to make different delay
times (Short, Medium, and Long
delay) at once. For example, to
use the short and middle heads,
select S+M.
Repeat Rate #1 0–127 Sets the tape speed.
This corresponds to the delay
time in a contemporary delay ef-
fect.
Intensity #2 0–127 Sets the repeat times of the de-
layed sound.
This is analogous to a contempo-
rary delay’s feedback setting.
Bass -100– +100 These are the echo sound’s bass
and treble adjustments.
When set to 0, they make no
change to the sound.
Treble
Head S Pan L63–63R These are the pan (left-right) set-
tings for each of the heads for
Short, Medium, and Long delay
time.
* This parameter does not
appear on the original RE-201.
Head M Pan
Head L Pan
Tape Distortion 0–5 Adds the distortion characteris-
tic of tape.
The distortion gets more intense
as the value is increased.
W/F Rate 0–127 Frequency of the wow and flut-
ter modulation
The wavering of multiple pitch-
es that appears from tape wear
and irregularities in rotation is
called wow and flutter.
W/F Depth 0–127 Modulation depth of the wow
and flutter
Echo Level 0–127 Volume of the echo sound.
Parameter Value Description
L
R
Tape Echo
