Installing the PC Card Protector
The V-Synth provides a PC card protector to prevent theft of the PC card. To install the PC card protector, use the
following procedure.
1.
Use a screwdriver to remove both of the screws from the bottom side of the PC CARD slot.
2.
Insert the PC card into the PC CARD card slot.
3.
Use the screws to fasten the PC card protector as shown below.
PC card protector
PC card
V-Synth rear panel
