Roland XV-3080 - Manual (Page 178)

178
MIDI Implementation
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600[cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400[cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100%
F7H EOX (End Of Exclusive)
❍ Controller
Status Data byte Status
F0H FH,7FH,09H,03H,0nH,ccH,ppH,rrH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
03H Sub ID#2 (Control Change)
0nH MIDI Channel (00 - 0F)
ccH Controller number (01 - 1F, 40 - 5F)
ppH Controlled parameter
rrH Controlled range
pp=0 Pitch Control
rr = 28H - 58H -24 - +24[semitones]
pp=1 Filter Cutoff Control
rr = 00H - 7FH -9600 - +9450[cents]
pp=2 Amplitude Control
rr = 00H - 7FH 0 - 200%
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600[cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400[cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100 %
F7H EOX (End Of Exclusive)
❍ Scale/Octave Tuning Adjust
Status Data byte Status
F0H 7EH,7FH,08H,08H,ffH,ggH,hhH,ssH... F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
08H Sub ID#1 (MIDI Tuning Standard)
08H Sub ID#2 (scale/octave tuning 1-byte form)
ffH Channel/Option byte1
bits 0 to 1 = channel 15 to 16
bit 2 to 6 = Undefined
ggH Channel byte2
bits 0 to 6 = channel 8 to 14
hhH Channel byte3
bits 0 to 6 = channel 1 to 7
ssH 12 byte tuning offset of 12 semitones from C to B
00H = -64 [cents]
40H = 0 [cents] (equal temperament)
7FH = +63 [cents]
F7H EOX (End Of Exclusive)
❍ Key-Based Instrument Controllers
Status Data byte Status
F0H 7FH,7FH,0AH,01H,0nH,kkH,nnH,vvH ... F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
0AH Sub ID#1 (Key-Based Instrument Control)
01H Sub ID#2 (Controller)
0nH MIDI Channel (00 - 0F)
kkH Key Number
nnH Control Number
vvH Value
nn=07H Level
vv = 00H - 7FH 0 - 200% (Relative)
nn=0AH Pan
vv = 00H - 7FH Left - Right (Absolute)
nn=5BH Reverb Send
vv = 00H - 7FH 0 - 127 (Absolute)
nn=5D Chorus Send
vv = 00H - 7FH 0 - 127 (Absolute)
F7H EOX (End Of Exclusive)
* This parameter affects drum instruments only.
● Data Transmission
This instrument can use exclusive messages to exchange many varieties of internal settings
with other devices.
he model ID of the exclusive messages used by this instrument is 00H 10H.
❍ Data Request 1 RQ1 (11H)
This message requests the other device to transmit data. The address and size indicate the
type and amount of data that is requested.
When a Data Request message is received, if the device is in a state in which it is able to
transmit data, and if the address and size are appropriate, the requested data is transmitted
as a Data Set 1 (DT1) message. If the conditions are not met, nothing is transmitted.
status data byte status
F0H 41H, dev, 00H, 10H, 11H, aaH, bbH, F7H
ccH, ddH, ssH, ttH, uuH, vvH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev devdevice ID (dev: 10H - 1FH, 7FH)
00H model ID #1 (XV-3080)
10H model ID #2 (XV-3080)
11H commandID (RQ1)
aaH address MSB
bbH address
ccH address
ddH address LSB
ssH size MSB
ttH size
uuH size
vvH size LSB
sum checksum
F7H EOX (End Of Exclusive)
* The size of data that can be transmitted at one time is fixed for each type of data. And
data requests must be made with a fixed starting address and size. Refer to the address
and size given in "Parameter Address Map (p.$$$)".
* For the checksum, refer to (p.$$$).
* Not received when the Receive Exclusive parameter (SYSTEM/COMMON) is OFF.
❍ Data set 1 DT1 (12H)
Status Data byte Status
F0H 41H, dev, 00H, 10H, 12H, aaH, bbH, ccH, F7H
ddH, eeH, ... ffH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH, Initial value is 10H)
00H Model ID #1 (XV-3080)
10H Model ID #2 (XV-3080)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the data to be sent
bbH Address: upper middle byte of the starting address of the data to be sent
ccH Address: lower middle byte of the starting address of the data to be sent
ddH Address LSB: lower byte of the starting address of the data to be sent.
