136
Chapter 9 Examples of Applications Using the XV-3080
MATRIX CTRL SRC (Matrix control
source)
If you wish to use controllers to control a specific Tone
parameter, select the controller on this page. Four control
sources are assigned to each Patch.
Control 1–4 (Matrix control 1–4 source)
Assign one of the following controllers to Control Source 1–4.
If you wish to use a controller that will apply to all Patches,
or a controller that cannot be directly specified here, select
SYS-CTRL1–4, and then select the controller using the
Control Source 1–4 parameters (SYS CTRL ASSIGN page).
OFF: No controller is used.
CC01–95: Controller numbers 1–95 (except for 32)
BEND: Pitch bend
AFTERTOUCH
SYS-CTRL1: Syetem Control 1
SYS-CTRL2: Syetem Control 2
SYS-CTRL3: Syetem Control 3
SYS-CTRL4: Syetem Control 4
VELOCITY
KEYFOLLOW
TEMPO
LFO1
LFO2
PITCH-ENV: Pitch Envelope
TVF-ENV: TVF Envelope
TVA-ENV: TVA Envelope
MATRIX CTR1–4 (Matrix control 1–4)
This selects the parameters controlled in Matrix Control
Source 1–4 and the Sens settings, as well as the Tone to which
they are applied. Up to four parameters can be specified for
each controller and controlled simultaneously.
The upper line of the display shows the name of the Control
Source selected on the MATRIX CTRL SRC page.
DEST1–4 (Destination 1–4)
Dest: This selects the parameters to be controlled.
OFF: No control
PITCH
TMT
EFFECTS parameters ([PATCH]-[EFFECTS] p. 21)
DRY LEVEL
CHORUS SEND
REVERB SEND
MFX CTRL1
MFX CTRL2
MFX CTRL3
MFX CTRL4
WAVE parameter ([PATCH]-[WAVE] p. 91)
FXM DEPTH
LFO parameters ([PATCH]-[LFO] p. 97)
LFO1 PCH DEPTH
LFO2 PCH DEPTH
LFO1 TVF DEPTH
LFO2 TVF DEPTH
LFO1 TVA DEPTH
LFO2 TVA DEPTH
LFO1 PAN DEPTH
LFO2 PAN DEPTH
LFO1 RATE
LFO2 RETE
PITCH parameters ([PATCH]-[PITCH] p. 92)
PIT ENV A-TIME
PIT ENV D-TIME
PIT ENV R-TIME
TVF parameters ([PATCH]-[TVF] p. 93)
CUTOFF
RESONANCE
TVF ENV A-TIME
TVF ENV D-TIME
TVF ENV R-TIME
TVA parameters ([PATCH]-[TVA] p. 95)
LEVEL
PAN
TVA ENV A-TIME
TVA ENV D-TIME
TVA ENV R-TIME
