Roland XV-3080 - Manual (Page 163)

163
Parameter List
Appendices
29:DISTORTION → CHORUS(p. 53)
The parameters are essentially the same as "26: OVERDRIVE → CHORUS,"
with the exception of the following two.
OD Drive → Dist Drive, OD Pan → Dist Pan
OD Drive → Dist Drive, OD Pan → Dist Pan
30:DISTORTION → FLANGER(p. 54)
The parameters are essentially the same as "27: OVERDRIVE → FLANGER,"
with the exception of the following two.
OD Drive → Dist Drive, OD Pan → Dist Pan
OD Drive → Dist Drive, OD Pan → Dist Pan
31:DISTORTION → DELAY(p. 54)
The parameters are essentially the same as "28: OVERDRIVE → DELAY," with
the exception of the following two.
OD Drive → Dist Drive, OD Pan → Dist Pan
OD Drive → Dist Drive, OD Pan → Dist Pan
32:ENHANSER → CHORUS(p. 54)
Parameter Value
Enhancer Sens Enhancer sens 0-127
Enhancer Mix Enhancer mix level 0-127
Cho Dly Chorus pre delay time 0.0-100.0 ms
ChoRate Chorus rate 0.05-10.00 Hz
Chorus Depth Chorus depth 0-127
Chorus Balance Chorus balance D100:0W-D0:100W
Level Output level 0-127
33:ENHANSER → FLANGER(p. 54)
Parameter Value
Enhancer Sens Enhancer sens 0-127
Enhancer Mix Enhancer mix level 0-127
Flg Dly Flanger pre delay time 0.0-100.0 ms
FlgRate Flanger rate 0.05-10.00 Hz
Flg Dpt Flanger depth 0-127
Flg Fbk Flanger feedback level -98-+98%
Flanger Balance Flanger balance D100:0W-D0:100W
Level Output level 0-127
34:ENHANSER → DELAY(p. 55)
Parameter Value
Enhancer Sens Enhancer sens 0-127
Enhancer Mix Enhancer mix level 0-127
Delay Delay time 0.0-500.0 ms
Dly Fbk Delay feedback level -98-+98%
Delay HF Damp Delay HF damp 200-8000 Hz,
BYPASS (*1)
Delay Balance Delay balance D100:0W-D0:100W
Level Output level 0-127
1: 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150,
4000, 5000, 6300, 8000 Hz, BYPASS
35:CHORUS → DELAY(p. 55)
Parameter Value
Cho Dly Chorus pre delay time 0.0-100.0 ms
ChoRate Chorus rate 0.05-10.00 Hz
Cho Dpt Chorus depth 0-127
Cho Bal Chorus balance D100:0W-D0:100W
DlyTime Delay time 0.0-500.0 ms
Dly Fbk Delay Feedback level -98-+98%
Delay HF Damp Delay HF damp 200-8000 Hz,
BYPASS (*1)
Delay Balance Delay balance D100:0W-D0:100W
Level Output level 0-127
1: 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150,
4000, 5000, 6300, 8000 Hz, BYPASS
36:FLANGER → DELAY(p. 56)
Parameter Value
Flg Dly Flanger pre delay time 0.0-100.0 ms
FlgRate Flanger rate 0.05-10.00 Hz
Flg Dpt Flanger depth 0-127
Flg Fbk Flanger feedback level -98-+98%
Flg Bal Flanger balance D100:0W-D0:100W
DlyTime Delay time 0.0-500.0 ms
Dly Fbk Delay feedback level -98-+98%
HF Damp HF damp 200-8000 Hz,
BYPASS (*1)
Delay Balance Delay balance D100:0W-D0:100W
Level Output level 0-127
1: 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150,
4000, 5000, 6300, 8000 Hz, BYPASS
37:CHORUS → FLANGER(p. 56)
Parameter Value
Cho Dly Chorus pre delay time 0.0-100.0 ms
ChoRate Chorus rate 0.05-10.00 Hz
Cho Dpt Chorus depth 0-127
Cho Bal Chorus balance D100:0W-D0:100W
Flg Dly Flanger pre delay time 0.0-100.0 ms
FlgRate Flanger rate 0.05-10.00 Hz
Flg Dpt Flanger depth 0-127
Flg Fbk Flanger feedback level -98-+98%
Flanger Balance Flanger balance D100:0W-D0:100W
Level Output level 0-127
38:CHORUS/DELAY(p. 57)
Refer to "35: CHORUS?DELAY."
39:FLANGER/DELAY(p. 57)
Refer to "36: FLANGER?DELAY."
40:CHORUS/FLANGER(p. 57)
Refer to "37: CHORUS?FLANGER."
41:STEREO PHASER(p. 57)
Parameter Value
Type Phaser type 1, 2
Mode Mode 4 stage, 8 stage
Pol Polarity INVERSE, SYNCHRO
Man Manual 0 – 127
Rate Phaser rate 0.05 – 10.00 Hz
Depth Phaser depth 0 – 127
Res Phaser resonance 0 – 127
X-Fbk Cross feedback level -98 – +98 %
Step Rate Step rate (*1) OFF, ON:0.1–20.0 Hz
Mix Mix level 0 – 127
LowGain Low gain -15 – +15 dB
Hi Gain High gain -15 – +15 dB
Level Output level 0 – 127
1: Step switch:Step rate
