M306H7T3-RPD-E User’s Manual 4. Hardware Specifications
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 76 of 88
4.5 Notes on Using This Product
Notes on using this product are listed below. When debugging the MCU using he emulator, be careful about the following
precautions.
IMPORTANT
Note on the Version of the Emulator Debugger:
Be sure to use this product with one of the following emulator debuggers.
1. M16C PC4701 Emulator Debugger
2. M3T-PD30 V8.20 Release 1 or later
Note on Selecting the MCU File:
It is necessary to make an MCU file which contains information such as, SFR area, internal RAM area
and internal ROM area, etc. to use this product. For creating an MCU file, see “3.1 Making an MCU
File” on page 48. For each memory map of MCU , refer to its data sheet.
Note on Malfunctions in the PC4701 System
If the emulator malfunctions because of interference like external noise, do the following to remedy the
trouble
(1) Press the RESET switch on the emulator upper panel.
(2) If normal operation is not restored after step (1), shut OFF power to the emulator once and then
reactivate it.
Notes on Downloading Firmware:
Before using this product for the first time, it is necessary to download the dedicated firmware (control
software built into the PC4701). Please note that, to do this, it is necessary to start up the emulator main
unit in maintenance mode. For firmware download procedures, see "2.6.2 Downloading Firmware in
Maintenance Mode" (page 28). Once the firmware has been downloaded, the product can be used by
simply turning on the power.
Do not shut off the power while downloading the firmware. If this happens, the product will not start up
properly. If power is shut off unexpectedly, redownload the firmware in maintenance mode.
Be sure to disconnect the user system before downloading the firmware.
Notes on the Self-check:
If the self-check does not result normally (excluding target status error), the emulation pod may be
damaged. Then contact your local distributor.
Be sure to disconnect the user system before executing the self-check
Note on Quitting the Emulator Debugger:
To restart the emulator debugger after it ends, always shut power to the emulator off once and wait
about 10 seconds, then turn the power on again.
