M306H7T3-RPD-E User’s Manual 2. Setup
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 22 of 88
2.3 Connecting the Host Machine
When connecting the emulator PC4701 to a host machine, interface varies depending on the PC4701 used. Figure 2.1 shows
the outline to connect each interface cable. For details on interface, refer to each PC4701 user’s manual used.
Table 2.1 Operating environment of the host machine
PC4701 Interface Remarks
Dedicated parallel
The special parallel interface cable is supplied with the PC4701HS.
For connection with the dedicated parallel interface, the parallel interface
printed circuit board (PCA4202G02: discontinued product) is required on
the host machine side.
Serial (RS232C)
The RS232C interface cable, 25-pin female/25-pin female conversion cable
and 25-pin female/9-pin female conversion cable are supplied with the
PC4701HS.
PC4701HS
LAN (10BASE-2/5) The LAN interface cable (10BASE-2/5) is supplied with the PC4701HS.
LPT parallel The LPT parallel interface cable is supplied with the PC4701M.
PC4701M
Serial (RS232C)
The RS232C interface cable and 25-pin female/9-pin male conversion cable
are supplied with the PC4701M.
LPT parallels The LPT parallel interface cable is supplied with the PC4701U.
USB The USB interface cable is supplied with the PC4701U.
PC4701U
LAN (10BASE-T)
No LAN interface cable is supplied with the PC4701U; it is, therefore,
necessary to arrange a LAN interface cable at your end.
