M306H7T3-RPD-E User’s Manual 2. Setup
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 25 of 88
2.4.3 PC4701 and Emulation Pod Arrangement
The PC4701 and emulation pod should be laid out so that the FLX120-RPD becomes straight as shown in Fig. 2.4 below
(indicated by circle).
Under the condition in which the FLX120-RPD has warped and there arises clearance in the slit, it is impossible to comply
with the overseas applicable standards (U.S FCC and CE Marking) to be satisfied by this product.
Figure 2.4 PC4701 and Emulation Pod Arrangement
CAUTION
Note on PC4701 and Emulation Pod Arrangement:
The PC4701 and emulation pod should be laid out in accordance with the explanation herein. In case
where these arrangements were carried out without following the explanation, it is impossible to keep
the overseas applicable standards (U.S FCC and CE Marking) that this product must satisfy..
There arises clearance in the slit.
