M306H7T3-RPD-E User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 55 of 88
3.3.2 Checking Connections of the Emulator System
Check to see that the emulator debugger has been connected correctly to the emulator.
Checking connections of the emulator system
When the emulator debugger is connected correctly to the emulator after you
have finished setting up the Init dialog box and the MCU Setting dialog box,
you will see a message “Connected” displayed on the “Debug” tab of the
Output window.
