M306H7T3-RPD-E User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 58 of 88
(2) Software break
1) Setting the software break point
Execution setup procedure with software break:
(1) By double-clicking the break point setting line on the software
break point setting column in the editor (source) window, the
break point can be set up and released. (In this case, the red circle
is displayed on the setting line as shown in the window on the
left.)
(2) Click the execution button.
2) Execution completed with software break
The cursor stops in the position where the software break was set up.
The statement in which the software break was set up is not executed.
