M306H7T3-RPD-E User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 54 of 88
(6) Script tab
Automatically executing a script command
To automatically execute a script command when starting up the
debugger, click the “Refer...” button and specify the script file to
be executed.
Clicking the “Refer...” button brings up a file selection dialog box.
The script file you have selected is displayed in the Init File:
section of the dialog box shown here. If you do not want to
automatically execute a script command, delete the character
string displayed in the Init File: section of the dialog box.
What you specify here is reflected at only startup. If you specify
back again in the Init dialog box after startup, whatever you
specified has no effect (restart the emulator debugger).
When the tab settings (1) to (6) above are completed, click OK button.
Cancel Help
