M306H7T3-RPD-E User’s Manual 2. Setup
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 26 of 88
2.5 Turning ON the Power
2.5.1 Checking the Connections of the Emulator System
Before turning the power ON, check the connection of the interface cable with host machine, PC4701, emulation pod, and user
system.
2.5.2 Turning ON/OFF the Power
Turn ON the power of the emulator and user system as simultaneously as possible.
Turn OFF the power of the emulator and user system as simultaneously as possible.
Do not leave either the emulator or user system powered on, because of leakage current the internal circuits may be
damaged.
When turning ON the power again after shutting OFF the power, wait for about 10 seconds.
IMPORTANT
Notes on Power Supply:
The emulator's pin Vcc is connected to the user system in order to monitor user system voltage. For this reason,
the emulator cannot supply power to the user system. Therefore, provide the user system with a separate power
supply from that of the emulator.
Keep user system power supply voltage within the following range.
(1) When JP4 is set as FLX:
2.0 V ≤ Vcc2 ≤ 5.5 V
2.0 V ≤ Vcc1 < Vcc2
(2) When JP4 is set as INT:
2.0 V ≤ Vcc1 = Vcc2 ≤ 5.5 V
Do not change user system power supply voltage after power has been activated.
