M306H7T3-RPD-E User’s Manual 1. Outline
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 19 of 88
Table 1.6 M306H7T3-RPD-E specifications (2/2)
Item Description
100-pin LCC socket 1 M30800T-PTC (included)
+ IC61-1004-051 (included) Connecting the user system
(see “2.8 Connecting the User System”
on page 31)
100-pin 0.65-mm-pitch QFP
(PRQP0100JB-A) 1 M30800T-PTC (included)
+ M3T-100LCC-DMS (not included)
+ M3T- DIRECT100S (not included)
2 M30800T-PTC
(included)
+ M3T-100LCC-DMS (not included)
+ M3T-DUMMY100S (not included)
3 M30800T-PTC
(included)
+ M3T-100LCC-DMS (not included)
+ M3T-FLX-100NRB (not included)
1.5 Operating Environment
Be sure to use this emulator with the operating environmental of the emulator and host machine listed in Tables 1.7 and 1.8.
Table 1.7 Operating environmental conditions
Item Description
Operating temperature 5 to 35°C (no dew)
Storage temperature -10 to 60°C (no dew)
Table 1.8 Operating environment of the host machine
Item Description
Host machine IBM PC/AT compatibles
OS
Windows 98SE
Windows Me
Windows XP
Windows 2000
CPU Pentium III 600 MHz or more recommended
Memory 128 MB or more recommended
Pointing device such as mouse Mouse or any other pointing device usable with the above OS that can be connected
to the main body of the host machine.
CD drive Needed to install the emulator debugger or refer to the user’s manual
* Windows is trademarks of Microsoft Corporation in the United states and other countries.
