M306H7T3-RPD-E User’s Manual 4. Hardware Specifications
REJ10J0964-0100 Rev.1.00 August 01, 2005 Page 75 of 88
4.4.2 External Dimensions of the M30800T-PTC
Figure 4.3 shows external dimensions of the converter board M30800T-PTC for a 100-pin LCC (included with the
M306H7T3-RPD-E).
Figure 4.3 External dimensions of the M30800T-PTC
1 30
31
50
CN
2
CN
1
100
81
80 51
MADE I N JAPAN
55.0
40.0
13.5
13.5
M30800T-PTC
10.8
16.3
External dimension when connecting the 100-pin LCC socket
Unit: mm
