User interface fundamentals

Main heading

Options

Description

Administration

System Information
Quick Start
Security ‡
CPU/Memory Utilization
Logout
Reset
Reset to Default

Configure and manage
administrative items

Support

Help
Release Notes
Manuals
Upgrade

Access to support facilities

† These options are available only if the switch is part of a stack.
‡These options have additional, associated options.

The following table describes Web-based management menu icons.

Icon

Description

Collapsed menu title
Click the icon to expand the menu and view all associated options.

Expanded menu title
All options associated with the menu title display underneath.
Click the icon to collapse the menu and hide associated options.

Menu option
Click the icon to display the management page associated with the
menu option.

Menu option with hyperlink to related pages

Menu option associated with an action
Actions have no associated management page and take place
immediately.

Link to Nortel home page
Click this icon to open a new Web browser window and load the
Nortel home page.

Management page

The Management page is the work area. Choose a menu command to
display the associated Management page on the right side of the screen.

The Management pages contain one or more of the elements in the
following table.
