38 User interface fundamentals
Establishing an SSH connection
Procedure Steps
Step Action
1 From the Device Manager main menu, choose Device > SSH
Connection.
2 On the toolbar, click SSH.
--End--
Trap log
Perform these procedures to configure and view the SNMP trap log.
Prerequisites
• Set the maximum number of trap entries. The default is 500.
• If you are using a UNIX platform, log on as root to receive traps.
•
Traps are received on port 162 by default.
• If port 162 is used by another application, disable the other application
and restart Device Manager.
Setting the maximum number of trap entries for the trap log
Procedure Steps
Step Action
1 From the Device Manager menu bar, choose Device >
Properties > Current to set the maximum number of trap
entries.
2 In the Max Traps In Log box, enter the maximum number of
traps you want to collect in the trap log.
3 Click OK.
--End--
Setting the trap port
Procedure Steps
Step Action
1 From the Device Manager menu bar, choose Device >
Properties > Current to set the trap port.
2 In the Trap Port box, enter the trap port number.
