Device Manager concepts 21
Device view
The Device view is a graphical representation of switch hardware
operating status and you can use it to perform management tasks on
specific objects. After you select a device from the Device menu, the
Device view appears.
Objects in the Device view are:
•
a stand-alone switch: called a unit in the menus and dialog boxes
• a switch stack: called a chassis in the menus and dialog boxes
•
a port
From the device view you can select single objects, groups of objects, or
the entire switch.
Device view object selection
Perform these procedures to select objects in Device view.
Selecting a single object in Device view
Procedure Steps
Step Action
1 To select a single object in Device view, a port for example, click
the edge of the object.
--End--
Selecting multiple objects in Device view
Procedure Steps
Step Action
1 To select multiple objects of the same type, for example a block
of contiguous ports, click and hold the right mouse button and
drag the pointer over the ports to select the group of ports.
2 To select multiple ports, or switches in the stack, Ctrl+click on
the objects.
--End--
Nortel Ethernet Routing Switch 2500 Series
Fundamentals
NN47215-102 01.01 Standard
27 October 2008
Copyright © 2008 Nortel Networks
.
