20 User interface fundamentals
Button Name Description Menu bar equivalent
Open Device Opens the Open
Device dialog box Device > Open
Refresh Device Status Refreshes the device
view information Device > Refresh
Status
Trap Log Opens the trap log Device > Trap Log
Help Opens online Help in a
Web browser Help > Device
Edit Selected Displays configuration
data for the selected
chassis object Edit > Unit
Edit > Chassis
Edit > Port
Graph Selected Opens statistics and
graphing dialog boxes
for the selected object Graph > Chassis
Graph > Port
Globe Opens a Web-based
management session Actions > Open Home
Page
Telnet Opens a Telnet
session Device > Telnet
SSH Opens an SSH
session Device > SSH
Connection
Alarm Manager Opens the Remote
Monitoring (RMON)
Alarm Manager Serviceability > Rmon
> Alarm Manager
Status bar
Device Manager provides a Status bar to display error and information
messages from the software applications. These messages are unrelated
to the managed device.
Nortel Ethernet Routing Switch 2500 Series
Fundamentals
NN47215-102 01.01 Standard
27 October 2008
Copyright © 2008 Nortel Networks
.
