Device Manager concepts 19
The Device Manager window includes the following parts:
• Menu bar: used to access command menus
• Toolbar: used for quick access to common commands
• Device view: used to show a graphic representation of the device
status
• Status bar: used to display error messages and other information
Menu bar
The following table describes the Menu bar commands. Feature availability
depends on switch model and configuration.
Command Description
Device Opens a device, refreshes the device view, rediscovers a device, and
sets the polling and SNMP properties.
From the Device menu you can also open and view the Trap Log,
SysLog, and Log and establish a Telnet or SSH connection to the
currently open device.
Edit Opens edit dialog boxes for the objects selected in the device view.
From the Edit menu you can also open dialog boxes for managing files
and running diagnostic tests, and enable SNTP, SNMPv3 and related
configurations.
Graph Opens statistics dialog boxes for the selected object.
VLAN Opens dialog boxes for managing VLANs, Spanning Tree Groups (STG),
MultiLink Trunking (MLT), and Link Aggregation Control Protocol (LACP).
IP Routing Opens configuration dialog boxes to set up IP routing functions, including
ARP, IPv4 TCP/UDP, DHCP, and UDP Forwarding for the switch, .
QoS Opens configuration and monitoring dialog boxes for Quality of Service
or Differentiated Services.
Rmon Opens configuration and monitoring dialog boxes for remote monitoring.
Actions Opens the Home page for the Web-based management session.
Help Opens online Help topics for Device Manager and provides a legend for
the port colors in the Device view.
Toolbar
The Toolbar contains buttons that provide quick access to commonly used
commands and some additional actions.
The following table describes the Toolbar buttons and provides Menu bar
equivalents.
Nortel Ethernet Routing Switch 2500 Series
Fundamentals
NN47215-102 01.01 Standard
27 October 2008
Copyright © 2008 Nortel Networks
.
