1
Connection and setup
LNB Type:
If your reception system does not have a Universal LNB, use the

buttons to select the LNB types that are used
in your reception system. You can choose from the following LNB types:
- Universal
- Simple or
- User-defined
LNB frequency (MHz):
You only need to specify this data if your LNB type is not “Universal LNB”. The data required differ for the settings “Simple”
and “User-defined”. Refer to the documentation supplied for your LNB.
- Selection “Simple” LNB: Use the numeric keypad to enter the LNB frequency
- Selection “User-defined”: Press the

button to input the required low, high and limit frequencies as necessary.
The input is performed using the numeric keypad
kHz signal:
You only need to specify this data if your LNB type is “Simple”. The 22 kHz signal is needed to switch LNBs when using
multi-feed reception and to switch between Low and High band.
- On
- Off
Test-Transponder:
Select the “Test-Transponder” field. Here you can select a transponder for checking whether your settings are correct
using the signal strength bar and signal quality bar.
When you have completed all settings for this satellite, press the

(green) button.
The receiver will automatically skip to the settings for the second tuner (assuming that for the second tuner you selected
the type of connection “Separated” and set the signal configuration to “Different from Tuner 1”). If this is the case, now make
the settings for the second tuner in the same way as you did for the first tuner.
Once you have completed the settings for both tuners and the satellites assigned to them, the receiver will automatically
display the screen for the channel search. Continue the first installation with the “Channel search” chapter.
