11
Information about antenna connection and loop-through mode
To enable you to utilise all the reception and recording features of your UFS 922 twin-PVR HDTV Sat receiver, such as
1. Recording one programme and simultaneously viewing any other programme or zapping through the channels, and
. Recording two different programmes at the same time,
the two tuner inputs on the satellite receiver must each be supplied with a dedicated satellite signal from the antenna
system/Sat outlet.
The receiver tuner inputs are factory preset in the installation menu to work with two separate Sat antenna connections.
If you only have one antenna connection available, we recommend you interconnect the output of tuner 1 and the input of
tuner 2 using the loop-through cable supplied.
For this, in “First Installation” for tuner input 2 select
“Loopthrough” (see “First Installation” chapter).
Press the
c button to access the “Tuner Configuration”
menu option, then select “Settings” and “First Installation”.
Go through step-by-step until you get to the tuner
configuration. You can make the settings here, However,
Loop-through cable
~
one restriction on this is that with tuner you can only receive the additional channels from the level currently set by
tuner 1 (e.g. Horizontal High).
Connection and setup
If you want to operate your UFS 922 on a one cable system, please refer to the connection example
for one cable systems (see “Technical appendix”, “Examples of one cable systems”).
This will only work when receiving one satellite, not with multi-feed reception!
