144
Tuner Configuration
Motorized Antenna (DiSEqC™1.2)
The individual items are selected using the

buttons. If you require to access submenus, they can be called up
using the

button. Changes to the current settings can be made using the

buttons or the numeric keypad.
Motor Control
Select the control type “DiSEqC™1.2”. Refer to the
documentation for your motorized antenna for details.
Go to Null Position
Select the “Go to Null Position” field. Press the

button
to instruct the turntable to move to its null position.
Set Borders
Select the “Set Borders” field. In this menu you can set the
limits for your turntable. This is particularly necessary if the
turntable has only a restricted range in which it can turn
before striking an obstruction (such as a wall or tree).
Press the

button. The following display appears:
The following buttons allow you to control the movement
of the turntable:

Start slow rotation to the West

Rotate to the West step by step

Stop the current movement

Rotate to the East step by step

Start slow rotation to the East
Once you have reached the desired East/West limit, switch to the respective field “Set current position for “****” border”
and press the

button to confirm.
If you subsequently want to delete the Set Borders, switch to the “Reset border positions” field and press the

button to confirm deletion of the limits. You can then set new values for the limits. Once you have set all the limits, press
the

button.
