Selecting Active Satellite
After installing the active pair of satellites, use the Select Satellite
menu to choose which of the installed satellites will be active.
Figure 3-17 Select Active Satellite
Setting the Skew
The Set Skew menu allows you to manually adjust the skew of
the antenna’s LNB.
Figure 3-18 Set Skew Menu
Using the MCU Interface
54-0198 73
Proceed to "Setting the Skew"
Select Satellite?
Yes Next Return
Select
Yes Next Cancel
Select
Yes Next cancel
Sat Name A
corresponds to the
first satellite selected
during the Install
Satellite process.
Sat Name B
corresponds to the
second satellite
selected during the
Install Satellite
process.
selected selected
Proceed to "Updating Satellite
Frequency Data"
Set Skew?
Yes Next Return
Skew: +##.#
- Enter +
Enter the desired skew.
Use the -/+ keys to set the sign
("-" or "+") and each number.
Selecting ENTER will cycle the
display through each digit, then
return to "Set Skew."
European systems only:
If DiSEqC is active on your
receiver, once the antenna restarts,
the antenna starts tracking the
satellite currently selected by the
receiver, overriding the Select
Satellite command.
The skew can only be set on a
system equipped with a linear quad
LNB/feed tube assembly. Otherwise
the following screen will appear:
No skew adjustment
with installed sats
