Installation
54-0198
47
Entering User-defined Satellite Data
Enter the following antenna commands to configure your user-
defined satellites. If you’re using HyperTerminal, type the command
in the HyperTerminal window then press Enter. If you’re using the
KVH Flash Update Wizard, type the command in the “Command” box,
then press Enter.
1. Enter the SATCONFIG parser command as follows:
Command:
SATCONFIG,USERX,YYY,Z,D,L
(
Where:
X = 1 (USER1 satellite) or 2 (USER2 satellite)
YYY = longitude (0-180)
Z = E (East) or W (West)
D = decoding type (0 = test, 1 = DSS-A,
2 = DSS-B, 3 = DVB)
L = LNB polarization (C = circular, L = linear)
Function:
configures one of the user-configurable satellites
with the longitude provided
Response:
if valid entry, echoes the input data
if invalid entry, returns error message
2. Type
@DEBUGON
to enter DEBUG mode.
3.
Enter the satellite’s transponder information as follows:
Command:
@SATCONFIG,X,N,F,S,C,ID,P,B,D
Where:
@SATCONFIG = directs data to the RF Board
X = satellite location (A = USER1, B = USER2)
N = satellite table # (98 = USER1, 99 = USER2)
F = frequency in MHz (either 00000 or within the
range 10700 - 12700)
S = the satellite transponder symbol rate in
Mbit/second (01000 - 29999)
C = the FEC code (e.g., 12, 23, 34, 56, 67, 78)
ID = the satellite network ID in hexidecimal format
(0x####)
P = the LNB polarization (v = vertical,
h = horizontal, r = right, l = left)
B = the LNB down conversion frequency (l = low,
h = high, G = Latin America, U = USA)
D = decoding type (1 = DSS-A, 2 = DSS-B,
3 = DVB)
