54-0198

130

TracVision G8 Owner’s Manual - Guide to Technical Information

Help on Parser Commands

Function:

lists parser commands

Command:

HELP

Argument:

none

Response:

print a list of all parser commands

Calculate Skew Angle

Function:

report skew angle of the current satellite

Command:

SKEWANGLE

Argument:

none

Response:

SKEW ANGLE = XXXX.X

D.2

Manual Positioning Commands

To execute the following commands, first put the antenna unit in
idle mode by typing HALT and pressing “ENTER.” Positioning
commands may be entered after the antenna comes to rest.

Azimuth Angle

Function:

commands a manual azimuth angle

Command:

AZ,xxxx (range is 0000-3599)

Argument:

desired azimuth angle of the mechanism relative to
baseplate fwd, 000°-359.9°

Response:

echoes the command; mechanism moves at a
fixed velocity

Elevation Angle

Function:

commands a manual elevation angle

Command:

EL,xxx (range is 100-850)

Argument:

desired elevation angle of the mechanism relative to
up, 10.0°-85.0°

Response:

echoes the command; mechanism moves at a
fixed velocity

Skew Angle

Function:

commands a manual LNB skew angle

Command:

SKEW,xxx (range is -1450 to 1450)

Argument:

desired skew angle of the LNB relative to up,
-145.0° to 145.0°

Response:

echoes the command; LNB moves at a fixed
velocity

If you enter the AZ, EL, or SKEW
command without any parameters,
the system reports the current
position for azimuth, elevation, or
skew.

The SKEW command is only
available if the antenna is equipped
with a linear quad LNB/feed tube
assembly.
