• Power cable to connect the MCU to ship’s power
(Table 2-2 provides proper gauge and length specifications
for a 12V supply. The system will not work if the MCU
receives less than 9V).
Table 2-2 Recommended Power Cable Specifications
Cable Length Cable Gauge
to 40 ft (12 m) 12 AWG (1.5 mm 2 )
up to 70 ft (21 m) 10 AWG (2.5 mm 2 )
Kitpack Contents
The kitpack packaged with your system contains hardware and
other materials that will be needed to complete the installation.
Ensure that the kitpack contains all of the items listed below.
Table 2-3 Kitpack Contents
Part Part # Qty.
M10 x 1.5 x 50 mm hex head bolts 14-0342-50 4
M10 flat washers 14-0344-10 4
M10 lock washers 14-0343-10 4
M4 x 0.7 x 8 mm pan-head Phillips screws 14-0075-08 6
Plastic screw covers 19-0088 8
Rear logo plate 20-0885-02 1
Power connector plug 23-0497-02 1
Receiver ground cable 32-0583-50 1
PC cable (for diagnostics) 32-0628-06 1
PC cable gender changer 23-0517-09 1
Flush mount MCU bracket 20-0667 1
Velcro self-adhesive backings 19-0146 4
Velcro washers 19-0147 4
#4-24 thread-forming screws 14-0150-06 4
Tie-wraps 22-0006 5
#8 type A screws 14-0047-08 4
#8 lock washers 14-0038 4
#6-32 x 1 ⁄
2
" pan head screws 14-0029-08 2
54-0198 22
