Appendix A: Disassembling and Reassembling the Cabinet 67
1. Using the 5/32" hex key from the accessory kit, remove the safety screw that’s located
inside each side handle. With the screen removed, you’ll find it easiest to reach inside
the cabinet and remove the screw through the hole above the handhold.
Figure 27: The Location of the Safety Screw in the Handhold
2. With the same hex key, remove the two safety screws on the underside of the top half
of the cabinet, on either side of the pen tray and control panel. (If you removed a
videoconferencing shelf, you already removed one of these screws.)
Figure 28: The Location of the Underside Safety Screw
To remove the top half of the cabinet
IMPORTANT
This procedure requires two people.
Hex Key
